3 stage, selectable 7.5/30 amp battery charger with adjustable settings for wet/gel battery types offers fast, reliable battery recharging
Dual C13 output receptacles pass 120V line power or inverter output through to connected equipment
3 position operating mode switch supports "AUTO" mode to enable automatic transfer between DC and AC modes, CHARGE-ONLY to maintain a full
battery charge
Set of six front panel LEDs display AC/DC operational modes, overload status, DC voltage level, shutdown status and system fault status
Set of 4 configuration dipswitches support wet/gel battery charging profiles, charger enable/inhibit, and selectable 144/163/182/201V AC low voltage auto
transfer during brownouts
Set of 4 additional configuration dipswitches support 4 levels of charger limiting relative to output load size, a battery equalization program and battery
charger low/high settings
Resettable 5A charger AC input breaker and resettable 6A AC output breaker and automatic 2 speed cooling fan protect the inverter from load and
temperature related failures
Automatic overload and thermal shutoff safely turns off inverter as excessive loads or overheating conditions develop
Front panel remote control connector enables remote off/on switching (requires APSRM4 switch accessory)
Specifications
OVERVIEW
Intended Application
OUTPUT
Frequency compatibility
Output watts
Continuous output capacity (watts)
Peak output capacity (watts)
Output nominal voltage
Output voltage regulation
Output frequency regulation
Overload protection
Outlet quantity / type
INPUT
Nominal Input Voltage(s) Supported
Recommended Electrical Service
Maximum input amps / watts
Input connection type
Emergency Home Power
50 Hz
1250
1250
2500
230V
LINE POWER (AC): Maintains 230V nominal sine wave output from line power source. INVERTER POWER (AC):
Maintains PWM sine wave output voltage of 230 VAC (+/-5%).
50 Hz (+/- 0.3 Hz)
Includes 5A input breaker dedicated to the charging system and 6A output breaker for AC output loads
2 Universal (IEC-320)
230V AC
DC INPUT: Requires 12VDC input source capable of delivering 125A for the required duration (when used at full
continuous capacity - DC requirements increase during OverPower and DoubleBoost operation). For automotive
applications, professional hardwire installation with 225A minimum battery system fusing is recommended. AC
INPUT: 230VAC
DC INPUT: Full continuous load - 125A at 12VDC. AC INPUT: 9.3A at 230VAC with full inverter and charger load
(3.3A max charger-only / combined input load to support charger and AC output is automatically controllable to
66%-33%-0% based on AC output loading using the charger limiting set points - see manual for setting instructions)
DC INPUT: Set of 2 DC bolt-down terminals. AC INPUT: IEC-320 C14 inlet connection
2 / 4
